1- 材料(MATERIAL) 胶芯:LCP、PA6T、PA9T、PA10T Housing: LCP、PA6T、PA9T、PA10T 方针:黄铜、磷铜、 Contact:Brass、Phosphor 2- 特性(characteristics): 额定电流:1 AMP Raring Current: 1 AMP . 接触阻抗:20MΩ MAX. Contact Resistance:20 MΩ MAX . 绝缘阻抗:1000 MΩMIN. Insulating Resistance:1000 MΩMIN. 耐电压:AC 300 V. Withstanding Voltage: AC 300 V. 温度范围:-55度至+105度 Temperture Range:-55℃to +105℃
|
